Dahua HY-GW01A Kablosuz Ağ Geçidi

General

Power Supply

5.0V/1.0A

Alarm Volume

70 dB

Alarm Mode

Visual and audible alarm

Indicator Light

Alarm, fault and operation indicator

LED Instructions

Standby: Green indicator stays on continuously
Pairing: Green indicator flashes quickly (once per 0.5 seconds)
Unpairing: All indicators stay on continuously for 3 seconds
Alarm: Red indicator stays on continuously
Fault: Yellow indicator stays on continuously
Distributed the network successfully: Blue indicator stays on continuously
AP distribution mode: Blue indicator flashes quickly (once per 0.5 seconds)
Reset: Red indicator flashes quickly (once per 0.5 seconds)

Wi-Fi Frequency

2.4 GHz (Incompatible with 5 GHz Wi-Fi network)

Wi-Fi Transmission Range

50 m (164 ft)

Wi-Fi Protocol

IEEE 802.11b/g/n

Operating Frequency

868 MHz

Maximum Number of Connected Devices

24 WisuLink wireless interconnected products

Color

White

Casing

ABS

Dimensions

L78.2mm × W78.2mm × H22.9mm (L3.08" × W3.08" × H0.90")

Weight

60 g (0.13 lb)

Installation

Free-standing/Wall mounting

Operating Temperature

-10°C to +55S°C (+14°F to +131°F)

Operating Humidity

?95% RH (non condensing)

Certifications

CE, UKCA
